CGS - Dual Analog Shift Register

The CGS Dual Analog Shift Register module is two sets of three sample and hold circuits cascaded. I bought the PCB's from Ken Stone of CGS. The front panel is from Bridechamber.com.

CGS - Dual Analog Shift Register - Front view

Front View

CGS - Dual Analog Shift Register - Back view

Back View
